Product Detail
| Product Name | China Best Quality Manufacture Yellow Brass Copper Red Pure Copper Plate /Sheet/Coil/Strip |
| Material | C10100 C10200 C11000 C12000 |
| C28000 C27400 C27000 C26000 C24000 C23000 C22000 C21000 | |
| C37000 C37710 C37700 C35300 C36000 C35600 | |
| Color | red, yellow, white |
| Standard | GB/T5231-2001.GB/T1527-2006.JISH3100-2006,JISH3250-2006,JISH3300-2006, ASTMB152M-06,ASTMB187,ASTMB75M-02,ASTMB42-02,etc |
| Thickness | 0.2mm~200mm |
| Width | 10mm~2500mm |
| MOQ | 100 KGS |
| Delivery time | within 15 working days |
| packing | standard seaworthy package |
| Loading port | Shanghai, Tianjin, Qingdao, Guangzhou |
| Used | manufacturing pins,rivets,gasket,nuts,conduits,the barometer spring,screen,radiator parts, etc |
Product Display
Product Packaging
Red copper brand comparison table | GB | JIS | DIN | ASTM | EN |
| TU0 | C1011 | -- | C10100 | C110 |
| TU1 | C1020 | OF-Cu | C10200 | C103 |
| TU2 | C1020 | OF-Cu | C10200 | C103 |
| T1 | C1020 | OF-Cu | C10200 | C103 |
| T2 | C1100 | SE-Cu | C11000 | C101 |
| T3 | C1221 | -- | -- | -- |
| TP1 | C1201 | SW-Cu | C12000 | -- |
| TP2 | C1220 | SF-Cu | C12000 | -- |
| GB | JIS | DIN | ASTM | EN |
| H59 | C2800 | CuZn40 | C28000 | CZ109 |
| H62 | C2720 | CuZn40 | C27400 | CZ109 |
| H65 | C2680 | CuZn35 | C27000 | CZ107 |
| H68 | C2600 | CuZn30 | C26000 | CZ106 |
| H70 | C2600 | CuZn30 | C26000 | CZ106 |
| H80 | C2400 | CuZn20 | C24000 | CZ103 |
| H85 | C2300 | CuZn15 | C23000 | CZ102 |
| H90 | C2200 | CuZn10 | C22000 | CZ101 |
| H96 | C2100 | CuZn5 | C21000 | -- |
| GB | JIS | DIN | ASTM | EN |
| HPb59-1 | C3710 | CuZn40Pb2 | C37000 | CZ120 |
| HPb59-3 | C3561 | CuZn40Pb3 | C37710 | CZ121Pb3 |
| HPb60-2 | C3771 | CuZn39Pb2 | C37700 | CZ120 |
| HPb62-2 | C3713 | CuZn38Pb2 | C35300 | CZ119 |
| HPb62-3 | C3601 | CuZn36Pb3 | C36000 | CZ124 |
| HPb63-3 | C3560 | CuZn36Pb3 | C35600 | CZ124 |
| Chemical Compositions about Pure copper. | ||||||||||
| Cu+Ag | Sn | Pb | Ni | Fe | Sb | S | As | Bi | o | |
| T1 | >=99.95 | <=0.002 | <=0.003 | <=0.002 | <=0.005 | <=0.002 | <=0.005 | <=0.002 | <=0.001 | <=0.02 |
| T2 | >=99.90 | <=0.05 | <=0.005 | <=0.2 | <=0.005 | <=0.002 | <=0.005 | <=0.002 | <=0.001 | <=0.1 |
| T3 | >=99.70 | <=0.05 | <=0.01 | <=0.2 | <=0.05 | <=0.005 | <=0.01 | <=0.01 | <=0.002 | <=0.1 |
| Chemical Compositions about Lead brass series | ||||||
| Grade | Main compositon | Impurity composition % | Impurity composition total % | |||
| Cu | Pb | Zn | Fe | Ni | ||
| HPb59-1 | 57-60 | 0.8-1.9 | Balance | ≤0.5 | ≤1.0 | ≤1.0 |
| HPb59-2 | 57.5-59.5 | 2.0-2.8 | Balance | ≤0.5 | -- | ≤1.2 |
| HPb59-3 | 57.5-59.5 | 2.0-3.0 | Balance | ≤0.5 | ≤0.5 | ≤1.2 |
| HPb60-2 | 58-61 | 1.5-2.5 | Balance | ≤0.3 | - | - |
| HPb62-2 | 60-63 | 1.5-2.5 | Balance | ≤0.15 | - | - |
| HPb62-3 | 60-63 | 2.5-3.7 | Balance | ≤0.35 | - | - |
| HPb63-3 | 62-65 | 2.4-3.0 | Balance | ≤0.1 | ≤0.5 | ≤0.75 |
| Chemical Compositions about Ordinary brass series | ||||||
| Grade | compositon | Impurity composition total % | ||||
| Cu | Zn | Pb | Fe | Ni | ||
| H59 | 57-60 | Balance | ≤0.5 | ≤0.3 | ≤0.5 | ≤1.0 |
| HP62 | 57-60 | Balance | ≤0.08 | ≤0.15 | ≤0.5 | ≤0.5 |
| H65 | 63.5-68 | Balance | ≤0.03 | ≤0.1 | ≤0.5 | ≤0.3 |
| H68 | 67-70 | Balance | ≤0.03 | ≤0.1 | ≤0.5 | ≤0.3 |
| H70 | 68.5-71.5 | Balance | ≤0.03 | ≤0.1 | ≤0.5 | ≤0.3 |
| H80 | 79-81 | Balance | ≤0.03 | ≤0.1 | ≤0.5 | ≤0.3 |
| H85 | 84-86 | Balance | ≤0.03 | ≤0.1 | ≤0.5 | ≤0.3 |
| H90 | 88-91 | Balance | ≤0.03 | ≤0.1 | ≤0.5 | ≤0.2 |
| H96 | 95-97 | Balance | ≤0.03 | ≤0.1 | ≤0.5 | ≤0.2 |
